Broadcom BCM5719 4-Port PCIe x4 1GbE Ethernet Kartı DELL HPE uyumlu
2.220,00 TL KDV dahil.
Marka
Stok Kodu
BCM5719-4P
Garanti Süresi
24 Ay
Ürün Durumu
Sadece Yeni ve Orjinal Kutulu Ürün satıyoruz.
Fiyat
2.220,00 TL KDV dahil.
Broadcom BCM5719 PCIe x4 Quad-port 1GBASE-T Ethernet Kartı |
DELL ~ HPE uyumlu
PCI Express (PCIe) x4 NetXtreme BCM5719-4P, IEEE 802.3ab standart Category-5 Kablo uyumlu
Dört portlu 10/100/1000 Mb/s Ethernet Kartı.
BCM5719-4P Ethernet adaptörü, büyük gönderim (Large Send), TCP segmentasyonu, TCP/UDP/IP kontrol toplamı ve Alıcı Tarafı Ölçekleme (RSS) gibi yük denetimi teknolojilerini destekler.
▪ Quad-port Gigabit Ethernet adapter
▪ IEEE802.3ab 10/100/1000Mb/s Gigabit Ethernet compliant
▪ Virtual LANs (VLANs) : IEEE802.1q VLAN tagging
▪ PCI Express v2.1 x4 at 5GT/s or 2.5GT/s
▪ Energy Efficient Ethernet-compliant with IEEE Standard Std 802.3az - 2010
▪ MSI-MSI-X capabilities-up to 17 MSI-X vectors
▪ I/O virtualization support for VMWare, NetQueue, and Microsoft VMQ
▪ 17 receive queues and 16 transmit queues per port
▪ 17 MSI-X vectors supporting per queue interrupt to host
▪ Function Level reset
▪ ECC error detection and correction on internal SRAM
▪ TCP, IP, and UDP checksum offload
▪ Large Send offload, TCP segmentation offload
▪ Receive-side scaling
▪ Jumbo frames 9.6KB
▪ IEEE802.3x flow control
▪ Statistics for SNMP MIB II and Ethernet -like MIB
▪ Comprehensive diagnostic and configuration software suite
▪ ACPI 1.1a-compliant multiple power modes
▪ Wake-on-LAN support
▪ Quad RJ45 with integrated link and activity LEDs
Broadcom BCM5719 4-Port PCIe x4 1GbE Ethernet Kartı DELL HPE uyumlu genel Özellikleri
| Slot Demirler | : | Low Profile ( Kısa Demir ), Full Height ( Uzun Demir ) |
| Port Tipi | : | RJ-45 |
| Transfer Hızı | : | 1.25 Gbps / Her Port |
| Port Sayısı | : | 4 Port Quad |
| Marka | : | StorNET, Broadcom |
| Bus type | : | PCIe 2.1 x4 |
| ChipSet | : | Broadcom |
| PoE tipi | : | PoE yok |
| Essentials | |
| Product Collection | NetXtreme GbE Network Adapter |
| Controller Processors | Broadcom BCM5719 |
| Bus Type/Bus Width |
PCI Express v2.1 x4 at 5 GT/s or 2.5 GT/s |
| Connections | 4 x RJ-45 (Copper ) Connector |
| Data Rate Supported | 10/100/1000 Mbps |
|
Cable Distances |
RJ45 Category 5, up to 100 m |
|
Bracket |
Full-height bracket installed. Low-profile bracket included in package |
| Dimension |
118 mm x 68 mm (PCIe Board) |
| Technical Specifications | |
|
IEEE standard/Network topology |
IEEE 802.3/10BASE-T, 100BASE-TX, 1000BASE-T |
|
Functional Features |
Supports MSI and MSI-X |
| Support TCP/IP Stateless Offloading and TCP/IP Offload Engine (TOE) | |
| Support Preboot eXecution Environment (PXE) | |
| System Requirements | |
| Windows Client | Microsoft Windows, Windows Hyper-V, Windows Server, CentOS, Debian |
| Linux |
Oracle Linux, Oracle Solaris, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, VMware, VMware ESX, VMware vSphere |
| Environment & Certification | |
| Power consumption (active-typical) | 5.78 W |
| Storage Humidity Maximum | 90% non-condensing relative humidity at 35 °C |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Operating Temperature | 0 °C to 55 °C (32 °F to 131 °F) |
| LED Indicators |
Link/Activity LED: off = No Link; on = Link; Blinking = Activity |
| Speed LED: Not illuminated = 10Mb/s; Green = 100Mb/s; Amber = 1 Gb/s | |
| Certifications | CE FCC RoHS |
